Carousel turning

Type: 1516, rotating diameter 1600, height 1000

• Max rotating diameter 160/1800 mm ( 1800mm is an option)
• Max turning length 1000 mm
• Ram horizontal movement 0 – 700 mm
• Ram vertical movement 0 – 630 mm
• Ram number 1 + side support
• Distance between face plate and ram 0 – 1225mm
• With horizontal sledge unit
• Speed range of spindle 4 – 200 rpm
• load capacity of face plate 5000 kg
• Capacity of main drive 30 kW
• Machine size 3190 x 3360 x 4100 mm
• Machine weight 18 000 kg
